The ECL-600 is a fire rated, code-compliant, rugged, dependable relatching exit device with a steel plate and photo-luminescent sign providing managed security and a 100 decibel alarm for secondary fire exits.

Rim cylinders available - sold separately

Details

• Rugged, dependable relatching alarmed exit device for secondary exits (ECL 600)

• Approximately 100dB piezo alarm

• 9-volt battery

• 1” throw, saw resistant deadbolt and deadlocking latchbolt provide 2-point locking (ECL-600)

• Resists over 2200 lbs outside pull force

• Photo-luminescent metal paddle sign

• Code-compliant, alarmed fire exit hardware (ECL-600)

• Tamper resistant housing with cover lock

• Non-handed

• Optional ECL-620 outside lever trim (ECL-600)

• Optional two-point locking (see VRA-143 and DX Bolts)

• Corrosion-resistant alloy lock body

• Signage available in many languages

Rated

• Warnock Hersey Labeled fire exit hardware for 3 hours, single or pairs of doors (ECL-600)

• Exceeds all Life Safety, ADA, California Title 19, ANSI/BHMA requirements for all building codes
